    MDK SYRINGE PUMP -06 Non Touch

    Kaarya

    MDK SYRINGE PUMP -06 Non Touch

    Rs. 0.00
    Rs. 0.00
    Sold out
    Tax included. Shipping calculated at checkout.
    16 people are viewing this right now

    Availability: In stock

    Our Advantages

    1. 1. GST Invoice
    2. 2. Brand New Products
    3. 3. Easy Replacements
    4. 4. Authorized Distributor
    5. 5. Best Price Guaranteed
    6. 6. Multiple Payment Options

    Shipping & Returns

    Free shipping and returns available on all orders!

    We ship all US domestic orders within 5-10 business days

    View full product details

    Machine Specificatipons

    • Maximum infusion pressure->150kPa
    • Occlusion Alarm: Detects occlusions in the infusion line and alerts the user
    • Air-in-Line Alarm: Detects air in the infusion line and alerts the user
    • Low Battery Alarm: Alerts the user when the battery level is low
    • Display: Backlit LCD display showing infusion parameters, alarms, and battery status.

    Key Feature

    • Model: MDK -06
    • Manufacturer: Medecin (a brand of Fresenius Kabi)
    • Type: Syringe Pump
    • Dimensions: 140 mm (W) x 220 mm (H) x 320 mm (D)
    • Weight: Approximately 2.5 kg (5.5 lbs)
    • Power Supply: 100-240 VAC, 50-60 Hz
    • Battery Life: Up to 8 hours (rechargeable battery)
    • Flow Rate: 0.1-120 mL/h (in 0.1 mL/h increments)
    • Syringe Size: 10mL, 20mL, 30mL, and 60mL
    • Pumping Mode: Continuous, Intermittent, and Bolus
    • Infusion Volume: 0.1-9999 mL (in 0.1 mL increments)
    • Infusion Time: 0-999 minutes (in 1minute increments)

    Certifications and Compliance

    • CE Mark: Conforms to EU Medical Device Directive 93/42/EEC.
    • FDA Clearance: 510(k) cleared by the US FDA.
    • ISO Certification: Meets ISO 13485:2016 standards for medical device quality management systems.

    Technical Specifications

    Parameter Specification
    Model Name/Number MDK -06 (Non-Touch variant)
    Infusion Accuracy $\pm 2\%$
    Syringe Size Compatibility 2 ml, 5 ml, 10 ml, 20 ml, 30 ml, and 50/60 ml
    Volume Infused (VTBI) 0.1 to 9999.9 ml (adjustable in steps of 0.1 ml)
    Occlusion Pressure Levels High ($100 \text{ kPa}$), Low ($50 \text{ kPa}$)
    KVO (Keep Vein Open) Rate

    • Flow Rate $\ge 10\text{ ml/h}$: KVO is $3\text{ ml/h}$


    • Flow Rate $1 \text{ to } 10\text{ ml/h}$: KVO is $1\text{ ml/h}$


    • Flow Rate $< 1\text{ ml/h}$: KVO = Current Flow Rate
    Safety Classification Class II, Type CF, IPX2 waterpro
