The HugeMed Portable Video Laryngoscope is a clinical airway management solution engineered to solve difficult intubations by prioritizing superior glottic visualization. It features a high-performance 2.0-megapixel full-view camera coupled with an anti-reflective display. Designed with ergonomic short-handles, built-in anti-fog mechanics, and options for both high-grade reusable stainless steel and single-use disposable polycarbonate blades, it bridges the gap between patient comfort, clinical workflow efficiency, and robust cross-infection prevention.
| Parameter | Specification Details |
| Display Monitor | 3.5-inch or 4-inch Full View LCD Screen |
| Resolution Ratio | 640×480 RGB (3.5") / 800×480 RGB (4") |
| Aspect Ratio | 4:3 |
| Video Refresh Rate | 30 FPS |
| Camera Sensor | 2.0 Megapixels CMOS |
| Field Angle (FOV) | 66° |
| Lens Illumination | High-power LED $\ge$ 800 LUX |
| Screen Rotation Angle | Tilts 140° up/down, swivels 180° left/right |
| Handle Mechanics | Anti-microbial, ergonomic short handle |
| Waterproof Grade | Monitor/Handle: IPX7 to IPX8 (supports immersion disinfection) |
| Storage Card | Built-in 8GB internal memory card |
| Data & Image Output | USB data interface (easy file copy, external display extension) |
| Battery Type | Rechargeable Lithium Battery (3.7V) |
| Battery Capacity | 3200 mAh – 3400 mAh |
| Continuous Operation | 120 to 150+ minutes on a full charge |
| Charging Duration | 4 to 6 hours (lifecycle over 300 cycles) |
Advanced High Definition View: The 2.0 MP camera paired with an anti-reflective screen allows for crisp, direct sight lines of the vocal cords.
Instant Smart Buttons: Features a quick-action operational button on the handle that takes a snapshot on a single click and triggers full video recording on a long press.
Intelligent Anti-Fogging: Built-in automatic heating element instantly activates to eliminate camera fogging from moisture during tracheal insertion.
Immersion-Safe Disinfection: Reusable variants feature 316 Medical Stainless Steel structures with an IPX8 waterproof rating, enabling deep-water immersion and chemical cleaning.
Rapid Blade Release: Smooth "drop-and-swap" mechanical locking system guarantees blade installation or swapping takes only seconds.
Zero Cross-Infection Options: Disposable blade modules are vacuum-sealed and fabricated out of high-transparency, shatterproof polycarbonate capable of handling mechanical torque over 300kg.
Ultra-Flexible Screen Articulation: Multi-angle adjustments allow the display to pivot freely, allowing clinicians to focus comfortably on the airway without stressing their posture.
Comprehensive Anatomical Scaling: Supports up to 8 tailored blade models including multiple Macintosh sizes (MAC 1 to MAC 5) for adult populations, Miller options (00, 0, 1) for neonatal/pediatric cases, and channeled alternatives.
Operating Theaters (OT) & Anesthesia: Everyday clinical intubation, teaching, and training layout presentation via external monitor connectivity.
Intensive Care Units (ICU): Rapid urgent airway stabilization for patients with severe compromised mobility or unpredictable vocal anatomy.
Emergency Medical Services (EMS) & Field Camps: Portable design and persistent battery life make it robust for off-site crash carts and rapid response scenarios.
HugeMed Video Laryngoscope Core Console / Handle Unit
Set of 3 Laryngoscope Blades (User-specified assortments: e.g., Choice of MAC 1-5 or Miller 00-1)
USB Charging and Data Transfer Cable
Dedicated Medical AC Power Adapter
Waterproof Seal Cap (for deep immersion cleaning model)
Official User Manual / Operator Guide
Heavy-Duty Protective Storage & Transport Case
