Patient Population: Neonatal, Pediatric, and Adult patients
Patient Weight Range: 0.1 kg to 300 kg
Display: 12.1-inch color touchscreen LCD (800 x 600 resolution)
Dimensions (Pneumatic Module): 10.5" H × 16.75" W × 16" D (26.7 × 43.2 × 40.6 cm)
Dimensions (User Interface Module): 13.75" H × 16.25" W × 2.5" D (35 × 41.3 × 6.4 cm)
Weight: ~83 lbs (37.6 kg) without compressor / 90 lbs (40.8 kg) with internal compressor
| Parameter | Range / Options |
| Respiratory Rate | 1 to 150 bpm (Neonatal/Pediatric), 1 to 120 bpm (Adult) |
| Tidal Volume | 2.0 mL to 2.5 L |
| Peak Flow | 0.4 to 150 L/min |
| Inspiratory Pressure | 0 to 80 $\text{cmH}_2\text{O}$ (Neonatal), 0 to 90 $\text{cmH}_2\text{O}$ (Adult/Pediatric) |
| Pressure Support (PSV) | 0 to 80 $\text{cmH}_2\text{O}$ (Neonatal), 0 to 90 $\text{cmH}_2\text{O}$ (Adult/Pediatric) |
| PEEP / CPAP | 0 to 50 $\text{cmH}_2\text{O}$ |
| Inspiratory Time | 0.15 to 5.0 seconds |
| $\text{FiO}_2$ (Oxygen Concentration) | 21% to 100% |
| Flow Trigger | 0.1 to 20 L/min |
| Pressure Trigger | 0.1 to 20 $\text{cmH}_2\text{O}$ |
Modes: Assist/Control (A/C), SIMV, CPAP/PSV, NPPV (Non-Invasive Positive Pressure), nCPAP/IMV
Breath Types: Volume, Pressure, APRV/BiPhasic, PRVC, Volume Guarantee, TCPL (Time-Cycled Pressure-Limited)
Apnea Backup: Volume, Pressure, or TCPL
Internal Battery: ~1 hour of ventilation standard (or 30 mins with internal compressor)
External Battery: Up to 4 hours of ventilation (or 2 hours with compressor)
Compressor Option: On-board scroll compressor for intra-hospital transport
BiCore™ Pulmonary Monitoring: Transpulmonary, esophageal, and tracheal pressure monitoring.
Volumetric Capnography: Real-time $\text{EtCO}_2$ and $\text{VCO}_2$ measurements.
Heliox Blending System: Internal automated Heliox gas delivery (concentrations from 80/20 to 0/100).
Active Exhalation Valve: Promotes ventilator synchrony and patient comfort.
